greenteQ handle/knob set, stainless steel, matt-brushed
DG60H.ER.RSW
VBH item no. 217271337
Slideshow
greenteQ Rosette handle/knob set for property doors.
greenteQ rosette handle/knob set DG 60H.ER.RSW made from matt brushed stainless steel, tested in accordance with DIN-EN 1906:47-0040B, category 4, with an 8 mm square spindle. The lever is mounted in a stationary/rotatable position on the inside rosette and has a holding spring.
The knob is mounted in a stationary position on the outside rosette. Concealed, end-to-end screw connection including screws for 37–46 mm door thickness.
Properties
Stationary / rotatable with holding spring
Rosette diameter: 55 mm
Edge height: 8.2 mm
Door thickness: 37–46 mm
Including 4 screws M4 x 50 mm
